NEW5010 Android 13 Unattended Payment Terminal – Rugged, Contactless POS for Self-Service & Public Applications

The NEW5010 Android 13 POS terminal is an unattended smart POS payment device designed for self-service and public applications. As a compact and lightweight Android POS machine, it combines industrial durability with modern payment technology, featuring IP65 protection and IK08 impact resistance for long-term, stable operation in demanding environments. This unattended POS system supports advanced POS connectivity and optional 2MP or 5MP front cameras, enabling flexible integration into kiosks, EV chargers, and automated payment terminals. Its modular design allows easy expansion, making it an ideal embedded POS solution for scalable projects.

Inquiry

Write a Review

SPECIFICATION

Model	NEW5010
OS	Asmart, Powered by Android 13
Processor	Cortex A53 Quad-Core, 2.0GHz + Secure Processor
Memory	2GB RAM + 8GB Flash 2GB RAM + 32GB Flash (Optional) Extended MicroSD Card Slot Up to 256GB
Card Readers	Magnetic Stripe, Chip & PlN, Contactless
Cameras	Front: 2MP Fixed Focus Front: 5MP Auto Focus (Optional)
Displays	4", TFT IPS, 480 x 480 Pixels Capacitive Touch Screen 2-points Touch
Communlcatlons	2G/3G/4G Wi-Fi (802.11a/b/g/n/ac), 2.4GHz & 5GHz Bluetooth5.0
Card Slots	*1Mini SIM + 1Mini SAM + 1Micro SD 1eSIM (Optional)*
Positloning	GPS, GLONASS, BEIDOU
Buttons	*1Settings**
Audio	*1Speaker**
Ports	*1USB Type-C OTG**
Adapter	Input: 100-240V AC, 50Hz/60Hz Output: DC 5V/3A
Physical	112 x 96.3 x 26.3mm, Cutout: 78.5 x 67.5mm 330g
Water & Dust Proof	IP52(Indoor Version) IP65(Outdoor Version)
Impact Protection	IK08
Operating Environment	Operating Temperature: -10℃~50℃ (14°F~122°F)(Indoor Version) Operating Temperature: -20℃~70℃ (-4℉~158℉)(Outdoor Version) Relative Humidity: 5%~95% (Non-Condensing)
Storage Environment	Storage Temperature: -20℃~60℃ (-4°F~140°F )(Indoor Version) Storage Temperature: -30℃~70℃(-22℉~158℉)(Outdoor Version) Relative Humidity: 5%~95% (Non-Condensing )
Certificatlons	PCI PTS 6.x, EMV L1 & L2, EMV CL1, Visa PayWave, MasterCard PayPass, Unionpay Quickpass, American Express, Discover D-PAS, JCB J/Speedy, Felica, MasterCard TQM, CE, FCC, RoHS

Product Advantage

The NEW5010 POS payment terminal accepts a wide range of payment methods, including magnetic stripe cards, IC cards, contactless NFC payments, and QR code transactions, ensuring full compatibility with modern cashless POS systems.

Product Introduction

Designed for self-service POS, kiosk POS, and unattended POS applications, the NEW5010 is widely suitable for EV charging stations, transportation ticketing, vending systems, parking solutions, and other automated payment scenarios, delivering security, reliability, and operational efficiency.
