NEW9010
NEW9010 verwendet Qualcomm-Chipsätze und ein leistungsstarkes Kommunikationsmodul, um eine schnelle und stabile Kommunikation und eine starke Netzwerkanpassungsfähigkeit zu gewährleisten.
NEW9010 akzeptiert Zahlungen mit Magnetstreifenkarten, IC-Karten, kontaktlos/NFC und 1D&2D-Codes.
Physische PIN-Eingabetastatur. Die Eingabe von Beträgen und Passwörtern ist bequemer und effizienter.
MODEL | NEW9010 |
| CPU | AP:Cortex Quad-core A53,2.0GHz SP:CS0 security core,60MHz |
| Operating System | Asmart Base on Android 12 |
|
Память
| 2G RAM+8G ROM |
| 2G RAM+16G ROM(optional) | |
| Display | 5"HD,IPS,1280*720,with adjustable backlight,Capacitive multi-touch screen,support electronic signature |
|
Card Reader
| Chip &PIN |
| Contactless | |
| Magnetic Stripe | |
|
Communication
| 4G/3G/2G |
| WFI 2.4G&5G | |
| Bluetooth 5.0 | |
| Location | GPS/BEIDOU/GLONASS |
|
Camera
| Front camera,2MP,FF |
| Rear camera,5MP,AF,support 1D/2D | |
| Physical Key | Numericx10 Function x5 Power x1 |
| Card Slots | 2x SIM+2xSAM 1xeSIM(optional) |
| Battery | 7.2V/2600mAh 7.2V/3200mAh (optional) |
| Printer | High-speed thermal printer Print Speed:90mm/s Paper Roll:58*40mm Metal paper cutter |
| Власть | Input:100-240VAC,50Hz/60Hz,Output:5.0V DC,2.0A |
| Certifications |
PCI PTS 6.x,EMV L1&L2,EMV CLL1,QUICS,TQM,PayWave,PayPass,American Express,Discover D-PAS,JCB,
Anatel,ABECS,ATEX,CE. |
| Environment | Operating Temperature:0℃~50° Storage Temperature:-20°℃~60° Relative Humidity:5%~95%(Non-Condensing) |
| Масса | 450g(including battery) |
| Размер | 190мм x80mmx57.4mm |
Note:This is only reference documents and products specification should be studied from the real products provided
Product advantage
●
High Performance：NEW9010 is based on the ARM Cortex-A53 Quad Core, a processor with the speed of 2.0GHz. NEW9010 is very premium on its performance.
●
Bigger Screen： NEW9010 is the portable POS terminal with a 5.0” big screen to deliver extraordinary visual and operation experience.
●
Physical PIN input keypad： Entering amounts and passwords is more convenient and efficient.
●
Use NEW9010 Anywhere：NEW9010 adopts Qualcomm chipsets and powerful communication module, to ensure fast and stable communication and strong network adaptability.
●
Printer speed greater than 90mm/s：Equipped with a metal paper cutter, with long service life and smooth paper tearing.
●
Payment Methods： NEW9010 accepts payments of magnetic stripe cards, IC cards, contactless/NFC and 1D&2D codes.
